Wireless rearview car 7 inch monitor by wifi transmission
Product Details
7inch car backup wireless camera kit
|
Specifications |
car wireless camera kit |
|
Screen Ratio |
16:9 |
|
Back Light Luminance |
LED, 300cd per square |
|
Resolution |
1024xRGBx600 |
|
Compatible system |
NTSC & PAL (automatically) |
|
OSD control |
Color, Brightness, Contrast, Volume, Language (English, Deutsch, French, Spanish, Portugal, Italian, Dutch, Simplify Chinese) |
|
View angle |
Hor. L(60) R(60) Ver. UP(40) DOWN(60) |
|
Image reversion |
UP/Down and Left/Right |
|
Power requirement |
12V DC (12-24V DC optional) |
|
Power consumption |
5W |
|
Storage temperature |
-30 - 80℃ |
|
Working temperature |
-20℃ to 70℃ |
|
Size |
172x115x22 mm |
|
Weight |
356g |
|
Key color |
Silvery color |
|
AV Inputs |
2 way video input, 1 mirror-link input |
|
Number of Trigger and display |
1 trigger |
|
Optional functions |
Built-in speaker, 4 PIN connector suitable |
|
Accessories |
Remote controller, Power supply cable , User manual, Bracket |
|
Package |
6pcs/box net weight:12.5KGS gross weight:13.1KGS |
|
Specifications |
Wireless Camera: EV-127AWD |
|
Image sensor |
CMOS |
|
Resolution |
420 TV line |
|
Minimum illumination |
0.1 Lux |
|
Image View angle |
120° |
|
System |
PAL& NTSC |
|
2.4G wireless transmitter |
The distance can reach 200M in the open area, Frequency point optional |
|
Power supply |
12V-24V |
|
Waterproof level |
IP 68 |
|
Appearance |
Aluminum alloy shell, outside hanging design |
|
Fit for |
Bus and truck and some special vehicles |
|
Other features |
Audio input, Waterproof, shockproof, Resistance to high temperature and humidity |
|
Accessories |
0.6m power cable |
